Swing over bed

1320mm (52")

Swing over cross slide

920mm (36.20")

Center height

650mm (25.60")

Bed width

900mm (35.40")

Spindle ranges

Auto 3 steps

Spindle speeds

S1: 5-110 r.p.m.
S2: 12-250 r.p.m.
S3: 27-550 r.p.m.

Spindle nose

A2-11 (Spindle bore 170mm)
A2-15 (Spindle bore 255mm)

Spindle bearing type

Taper roller

Spindle bore

170mm (6.70") / 255mm (10")

Longitudinal travel (Z1-axis)

1100mm (43.30")

Longitudinal travel (Z2-axis)

300mm (11.80") / Manual 4-way tool post only

Cross slide travel (X-axis)

700mm (27.50")

Ballscrew diameter X-axis

32mm (1.25")

Ballscrew diameter Z-axis

50mm (2")

Rapid traverse X-axis

10m/min (394"/min)

Rapid traverse Z-axis

10m/min (394"/min)

Cross slide dimension

1000mm (39.40") x 290mm (11.40")

Main spindle motor

25HP (Standard) / 30HP (Optional)

X-Axis servo motor

1.9 KW

Z-Axis servo motor

3.6 KW

Coolant pump motor

1/4HP (Standard)
3/4HP High pressure pump (Optional)

Machine length

4000mm (157.50")

Machine width

2200mm (86.60")

Machine height

2170mm (85.40")

Packing dimension

165"(L) x 90"(W) x 90"(H)

Net weight


Gross weight


*Design and specifications are subject to change without notice.
